The solar drying system (also known as solar air heating system or solar dryer) is an innovative, sustainable heating solution designed to maximize the conversion of sunlight into usable heat for industrial drying and space heating. Developed by Solaraven, this system leverages advanced solar vacuum tube technology to deliver exceptional heat efficiency, reduce reliance on conventional energy sources (electricity or gas), and minimize maintenance costs. Whether for large-scale industrial drying or residential space heating, the solar drying system offers a cost-effective, eco-friendly alternative that aligns with green energy goals.
The core component of the system is the air heating solar collector, equipped with 30 dual-end open solar vacuum tubes per unit. These tubes efficiently absorb solar radiation and convert it into thermal energy, with an inner tube temperature reaching up to 250℃, ensuring rapid and consistent heat transfer to circulating air.
On sunny days, a single solar air heating panel can easily achieve an air heating temperature of 90℃. For higher demand, an array of collectors can boost the maximum air heating temperature to 140℃, meeting the needs of various high-temperature drying applications.
With a unique air circulation design inside the vacuum tubes, the system eliminates common issues like leakage, freezing, and overheating. Even if one tube is broken, the system continues to operate seamlessly, ensuring uninterrupted performance.
Optimized for efficiency, the system features a large air flow rate that enhances heat distribution, ensuring uniform drying and heating across the target space or materials.
Parameter | Details |
Model | 58/1800-30 |
Brand | Solaraven |
Product Code | 8419120000 |
Absorber Area | 5㎡ |
Output Power | 2KW (16KWH heat generated per 8-hour sunny day) |
Working Mode | Solar air heating |
Air Heating Temperature | 90℃ - 140℃ |
Solar Collector Configuration | 30 dual-end open solar vacuum tubes per unit + 2 air flow circulation manifolds |
Maximum Vacuum Tube Inner Temperature | 250℃ |
Clothing and fabric drying (large-scale factory use with 1800+ solar heating tubes)
Paper tube drying, wood drying, and printing drying
Tobacco drying, herbal medicine drying, and vegetable drying
Chemical drying (multiple chemical processing scenarios)
Ideal for 40㎡ residential spaces, the system can be configured with 2 air heating solar panels (60 vacuum tubes total) to maintain a comfortable indoor temperature of 18℃ even when the outdoor temperature drops to -10℃. It can be paired with a wall-hanging stove for nighttime heating.
By harnessing solar energy, the system reduces carbon emissions and lowers energy bills, making it a sustainable choice for businesses and homeowners alike.
The durable design and absence of complex mechanical parts minimize maintenance requirements, reducing long-term operational costs.
From industrial production lines to residential homes, the system’s flexible configuration (single unit or array) adapts to diverse drying and heating needs.
With no risk of leakage, freezing, or overheating, the system ensures safe use in various environments, from cold winters to hot summers.
Ready to elevate your drying or heating process with clean, efficient solar energy? The Solaraven solar drying system is in stock and available for immediate inquiry. Contact our team today to discuss your specific needs, request a customized quote, or add the system to your basket. Join the green energy revolution—invest in a solar drying system that delivers performance, sustainability, and long-term savings!
