| Quantity: | |
|---|---|
RNE-NC-10
SOLARAVEN
841912
The Solar Geyser redefines affordability and performance in solar water heating, merging compact design with industrial-grade durability. Its lightweight yet robust aluminum frame and copper-core heat exchangers enable 30% faster heat transfer compared to standard models, making it ideal for urban apartments and rural homesteads alike. The system operates silently at 98% thermal efficiency, leveraging advanced phase-change materials to store excess heat for nighttime use. Compatible with IoT ecosystems, it offers customizable temperature profiles and energy usage analytics, empowering users to optimize consumption. With frost-resistant valves and tropicalized components, it performs flawlessly in climates ranging from -20°C to 50°C, democratizing access to clean hot water worldwide.
1. Copper Helical Heat Exchangers: High-purity copper coils increase surface area for rapid heat absorption, achieving 70°C water within 2 hours of peak sunlight.
2. Aerospace-Grade Aluminum Frame: Powder-coated, rust-proof frame reduces total weight by 25% while supporting rooftop installations on lightweight structures.
3. All-Climate Resilience: Self-draining technology and PTFE-coated tubes prevent freezing damage, while UV-resistant polymers combat degradation in tropical sunlight.
4. Interactive LCD Dashboard: Displays real-time metrics like daily energy saved, CO2 emissions reduced, and system diagnostics in 6 languages.
5. Plug-In Scalability: Connect up to 4 units via daisy-chained ports for expanded storage (up to 1200L) without additional controllers.
6. E-Waste Reduction: 95% recyclable components and a take-back program align with circular economy principles.
· High-Rise Buildings: Compact units fit balcony railings or vertical mounts, serving urban apartments with limited space.
· Mobile Clinics: Provides sterilized hot water for medical equipment in remote healthcare setups.
· Food Trucks: Supports kitchen hygiene and dishwashing for mobile catering businesses.
· Sports Complexes: Fuels locker room showers and hydrotherapy pools in stadiums and gyms.
Q: How efficient is the system during monsoon seasons?
A: Efficiency drops marginally to 70–80% during heavy rain, but built-in thermal retention ensures 8–12 hours of hot water availability post-sunlight.
Q: Can the geyser be moved after installation?
A: Yes, the lightweight panels and detachable plumbing allow easy relocation. A reinstallation kit with sealants and brackets is included.
Q: Are financing options available?
A: Partner financial institutions offer low-interest green loans and lease-to-own plans in select countries.
Q: How are defective tubes replaced?
A: Tubes can be individually replaced without draining the tank. Spares are shipped globally within 5–7 business days.
Model | Vacuum Tube | Capacity | Absorber Area | Suitable for | |
Pcs | Size(mm) | (L) | (㎡) | (Persons) | |
RNE-NS-10 | 10 | 58×1800 | 100 | 1.330 | 2 |
RNE-NS-15 | 15 | 58×1800 | 150 | 1.995 | 3 |
RNE-NS-20 | 20 | 58×1800 | 200 | 2.660 | 4 |
RNE-NS-25 | 25 | 58×1800 | 250 | 3.325 | 5 |
RNE-NS-30 | 30 | 58×1800 | 300 | 3.990 | 6 |
Gravity Solar Geyser with vacuum tubes | |||
Solar Water Tank | 1 | Material of Outer Tank Shell | stainless steel 304 2B or 316L |
2 | Material of Inner Tank Chest | stainless steel 304 2B or 316L | |
3 | Water Tank Diameter | 【460/360MM】 | |
4 | Water Tank Insulating Layer | Imported Polyurethane,High Density,【50MM】 | |
5 | Heat Preservation Period | 72～80Hours | |
6 | Welding Method | Argon Arc Welding | |
Solar Vacuum Tube | 7 | Solar vacuum tube structure | All-Glass Double Co-Axial Structure |
8 | Glass Material | High Borosilicate 3.3 Glass | |
9 | Tube Size | 【diameter 58MM* length 1800MM】 | |
10 | Outer Tube Dia.&Glass Thickness | φ58±0.7mm,Glass Thickness 1.6±0.15mm | |
11 | Inner Tube Dia.&Glass Thickness | φ47±0.7mm,Glass Thickness 1.6±0.15mm | |
12 | Coating Material | 【CU/SS-ALN(H)/SS-ALN(L)/ALN】 | |
13 | Sediment Method | Tri-Element Magnetron Sputtering Plating | |
14 | Absorb Ratio | >96%(AM1.5) | |
15 | Thermal Emissivity | ≤6%/(80℃) | |
16 | Hail Resistance | φ25mm | |
Solar water heater Bracket | 17 | Bracket Material | 【Stronger Galvanized Steel】 |
18 | Bracket Angle | 【25°】 | |
19 | Bolts&Muts | Stainless Steel | |
Assistant Tank | 20 | Assistant Tank Material | Stainless steel |
21 | Assistant Tank Capacity | 【5L/8L/20L】 | |
22 | Assistant Tank Model | Vertical/Horizontal,Optional | |
